BenQ PB8230 DLP Projector Information
Specifications
Aspect Ratio 4:3 (Native), 5:4, 16:9
Brightness 2500 ANSI Lumens
Contrast Ratio 2000:1
Display Type 0.7" DLP
Resolution (Native/Max) XGA (1024 x 768) SXGA (1280 x 1024)
Video Compatibility NTSC / PAL / SECAM / HDTV
Projection Lens F = 2.6 ~ 3.1
Number of Colors 16.7 Million Colors
Size Dimensions (WxHxD) 12.1in. x 3.7in. x 9.4in.
(30.73cm x 9.4cm x 23.88cm)
Weight 6.8 lbs. (3.08 kg)
Inputs 1 x VGA input - 15 pin HD D-Sub (HD-15)
1 x composite video input - RCA
1 x component video input - RCA x 3
1 x S-video input - 4 pin mini-DIN
1 x audio line-in - RCA x 2
1 x audio line-in - mini-phone stereo 3.5 mm
Outputs 1 x VGA output - 15 pin HD D-Sub (HD-15)
Audio Integrated 3 Watt Monaural Speaker
Control: 1 x serial RS-232, 1 x USB
Power Supply 100 ~ 240 V / 50 ~ 60 Hz 330W
Audible Noise 34 dB
Operating Temperature 50°F ~ 104°F (10°C ~ 40°C)
Lamp Type 250W UHP, Life 2000 hrs
Projection Distance 2.6ft. ~ 32.8ft. (0.79m ~ 10m)
Projection Size (Diagonal) 20in. ~ 300in. (50.8cm ~ 762cm)
Brightness Uniformity 85%
H-Sync Range 20 ~ 88 kHz
V-Sync Range 20 ~ 100 Hz
Menu Languages Chinese (traditional), Chinese (simplified), English, German, French, Italian, Spanish, Korean
